    50 Tons Tipper Dump Semi Trailer 30-45m3 Volume For Transport Sand Stone

    Ask Lasest Price
    Brand Name : TRUCKMAN AUTO
    Model Number : TKM370TTT
    Certification : SGS, BV, CIQ
    Price : Price is negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 1500 Unit / Per Month
    Delivery Time : 20-25 working days
    • Product Details
    • Company Profile

    50 Tons Tipper Dump Semi Trailer 30-45m3 Volume For Transport Sand Stone

    50 Tons Tipper Trailer Dump Semi Trailer Used For Transport Sand Stone


    1. 3 Axles Dump Semi Trailer Specification.


    -. Dump trailers Axle: FUWA / BPW, Tri axle


    -. Dump trailers volume: 30-45m3


    -. Semi-trailer type rear end dump trailers.


    -. Factory price and fast delivery time


    Tare Weight7.85T-8.5T
    Payload60T(25m³--37m³)
    Axle Weight Load16T FUWA axle
    AxleThree, FUWA Brand
    SuspensionThicken mechanical suspensions
    King Pin50#/90# traction pin
    Dimensions(L*W*H)11280*2495*3970(Outside)
    10500*2300*1500(Inner)
    Rim8.5-20 * 12 pieces
    Lifting systemFour or five ø125lifting cylinders, one piece of ø140 displacement
    cylinder
    Steel Spring10 pieces
    Tire specs12.00R22.5
    Number of Tire12 pieces
    Spare Tire Carriers2 pieces
    Frame: (specs. and materials)Main frame is height 500mm,
    Frame BeamUpper plate is 16mm, lower plate is 18mm, middle is double 6mm.
    side beam is 16# U steel. Left side: 3 or 4 pcs French door;
    Right side: 3 or 4 pcs hanging door. With19 pcs lock bar.
    Frame FloorThe Thickness is 3mm flat bed
    BrakeKemi Brand of China
    Brake Chamber6 double chamber
    ABSKemi Brand of China (4S/2M)
    Electrical Voltage24V
    Receptacle7 ways (7 wire harness)
    Light color Side marker lampOrange
    Rear lampRed
    Turn signal lampOrange
    LegsJost D200T

    50 Tons Tipper Dump Semi Trailer 30-45m3 Volume For Transport Sand Stone


    50 Tons Tipper Dump Semi Trailer 30-45m3 Volume For Transport Sand Stone


    -2. FAQ


    -. Terms of paymemt.

    30% as the deposit by T/T, 70% balance before delivery.


    -. What’s your MOQ?

    One unit trailer or truck. But suggest two trailers one time to save the freight.


    -. Whats your delivery time.

    20-25 working days after received the deposit.


    -. What is your terms of shipment?
    The trailer could arrange shipment by ro-ro ship, bulk cargo vessel, container etc.


    -. Can you accept the custom made?

    Definitely! We could design the trailer according to your request.


    -. What’s your warranty?

    All of our trailers meet the CIQ, SGS, BV, ADR, FORM E quality certificate, and we will supply one year warranty for the trailers.
