6x4 Sinotruck Howo Tipper Truck 25 Tons Loading

    Buy cheap 6x4 Sinotruck Howo Tipper Truck 25 Tons Loading from wholesalers

    Buy cheap 6x4 Sinotruck Howo Tipper Truck 25 Tons Loading from wholesalers
    • Buy cheap 6x4 Sinotruck Howo Tipper Truck 25 Tons Loading from wholesalers
    • Buy cheap 6x4 Sinotruck Howo Tipper Truck 25 Tons Loading from wholesalers
    • Buy cheap 6x4 Sinotruck Howo Tipper Truck 25 Tons Loading from wholesalers
    • Buy cheap 6x4 Sinotruck Howo Tipper Truck 25 Tons Loading from wholesalers

    6x4 Sinotruck Howo Tipper Truck 25 Tons Loading

    Ask Lasest Price
    Brand Name : HOWO
    Model Number : ZZ3257N3647A
    Certification : SGS,BV,CIQ,ECTN,CO,FORM F
    Price : Dollars 43500-44500 Unit
    Payment Terms : T/T
    Supply Ability : 500 Units Per Month
    Delivery Time : 30 working days
    • Product Details
    • Company Profile

    6x4 Sinotruck Howo Tipper Truck 25 Tons Loading

    SINOTRUK HOWO Dump Truck

    With its reliable and stable structure design, high bearing capacity, excellent engine force, highly stable performance, and its frame forged in construction and mining industries with adverse operating environments, it is widely used for the short-range earthwork transportation tasks for mines and construction projects. It is world widely accepted by users from South East Asia, Middle East, Africa, South America countries. Without any question, HOWO dump truck is NO. 1 option for your project.

    ModelGCW40000kgs Driving Type 6×4 RHD/LHD howo dump truck
    Engine

    Engine model: WD615.69/WD615.47, Euro II emission standard

    4 stroke direct injection diesel engine

    6 cylinder in-line with water cooling, turo-charging & intercooling

    Maximum output: 336hp(273Kw) at 2200 rpm according to DIN

    Maximum torque: 1450Nm at 1300~1600 rpm

    Bore: 126mm; Stroke: 130mm;

    Displacement: 9.726L; Compression ratio: 17:1

    Specific fuel consumption: 198g/kWh; Engine oil filling quantity: 20L

    Cooling system filling quantity (long-term filling): 40L

    Thermostat opening temperature: 71oC

    Rigid fan Twin cylinder air compressor

    ClutchSINOTRUK’s 430C diaphragm spring clutch, hydraulically operating with air assistance
    Transmission

    Transmission, model HW19710, 10 forward and 2 reverse

    Ratio:14.28; 10.62; 7.87; 5.88; 4.38; 3.27; 2.43; 1.80; 1.34; 1.00; 13.91/3.18(R)

    Propeller ShaftDouble universal joint propeller shaft with gear-shaped coupling flange
    Front Axle

    New HF9 series, with drum brake system

    Steering with double T-cross section beam

    Rear Axle

    HC16 pressed axle housing, single reduction and differential locks between axles; with drum brake system.

    Ratio: 5.73

    Chassis

    Frame: High-strength U-profile frame, all cold riveted cross members and reinforced subframe

    Front suspension: semi-elliptic leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer

    Rear suspension: semi-elliptic leaf springs and bogie springs

    Spare wheel carrier: with one spare wheel

    Steering

    ZF8118, hydraulic steering with power assistance

    Ratio: 22.2-26.2:1

    Braking System

    Front and rear drum brake, four-circuit protection valve

    Service brake: dual circuit compressed air brake

    Parking Brake: spring energy, compressed air operating on rear wheels

    Auxiliary brake: engine exhaust brake

    Wheel & Types

    Rims: 8.5-20,10 hole-steel

    Types: 12.00R20, 12.00R22.5, 315/80R22.5, 12.00-20

    Driver’s cabHW76 Long cab, all steel forward control, 55° hydraulic tilting to the front, 2-arm windscreen wiper system with 3 speeds,VDO electrical control system, laminate windscreen, with casted-in radio aerial, adjustable driver’s seat and rigid adjustable co-driver’s seat, heating & ventilation system, with stereo radio/cassette recorder, one sleeper,sun visor, safety belt, air conditioner, adjustable steering wheel.
    Electrical System

    Operating voltage:24V, negative grounded

    Starter: 24V, 7.5KW

    Alternator: 3-phrase, 28V, 1540W

    Batteries: 2×12V, 165Ah

    Cigar-lighter, horn, headlamp, fog light, brake lights, indicators and reverse lamp

    Dimensions in mm

    Wheel base (mm)

    Front wheel track (mm)

    Rear wheel track (mm)

    Front overhang (mm)

    Rear overhang (mm)

    Approach angle(°)

    Departure angle(°)

    Carriage Dimension (mm)

    3425+1350

    2022/2041

    1830

    1500

    1859

    19

    23

    5200x2300x1500 mid lifting, floor 8mm side 6mm

    Weight in kg

    Permissible loading capacity (kg)

    Dead weight (kg)

    Gross vehicle weight (kg)

    Gross combination weight (kg)

    Front axle loading capacity (kg)

    Rear axle loading capacity (kg)

    30000

    12090

    25000

    30000

    9000

    2×16000

    Performance

    Maximum driving speed(km/h)

    Maximum gradeability (%)

    Minimum ground clearance(mm)

    Minimum turning radius (m)

    Fuel consumption(L/100km)

    75(reference data)

    36

    314

    15

    40(reference data)


    Roll on roll off (RORO) ship
    It's the specialized ship to transport cars and trucks, which has power wheel, it's the best way of truck transportation.
    Bulk carrier ship
    It's the specialized ship to transport grain, coal, ore, salt, cement ,etc, dry and bulk goods, can also used to transport trucks,price is cheap, but the truck always be put on the deck, sea water will damage the truck painting.
    Container ship
    It's well-known shipping way, and also the highest cost among these three ways. Few sea port only container ship can arrive, so
    sometimes, we have to use container ship.


    TRUCKMAN AUTO Another mainly business is for China Truck spare parts,which the quality is reliable but with very competitive price.,welcome inquiry.
