    3 Line 6 Axles Truck Trailer Low Bed , Low Bed Lorry Loading 100 Tons

    Ask Lasest Price
    Brand Name : TRUCKMAN AUTO
    Model Number : TKMS67M
    Certification : BV, CTN, SGS, CE
    Price : Price is negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 1500 Unit / Per Month
    Delivery Time : 20 days
    • Product Details
    • Company Profile

    3 Line 6 Axles Truck Trailer Low Bed , Low Bed Lorry Loading 100 Tons

    China Heavy Duty Low Bed Trailer With 3 Line 6 Axles Loading 100 Tons


    1. Main Function Of Low Bed Trailer.


    -. Low flatbed semi-trailers are usually used to transport heavy vehicles (such as tractors, buses, special vehicles, etc.), rail vehicles, mining machines, forestry machines, agricultural machines (such as excavators, bulldozers, loaders, pavers, cranes, etc. ) And other heavy cargo

    -. The lower the center of gravity, the better the stability and security, and the greater the ability to transport super high cargo and pass overhead obstacles


    Trailer Model3 Axle low bed Semi Trailer
    Total size13000*3000*1650mm
    Working size(Lx W x H)(mm)9000*3000*1300mm
    Curb Weight(KG)7000
    Loading Weight(KG)60000
    Departure Angle16
    Axle Brand13TON Axle HJ Brand
    Axle NumberThree
    Wheelbase(mm)8580+1310+1310
    Suspension systemLeaf spring suspension
    Steel Spring10/10/10 leaf spring suspension
    The material of Main beamThe height of the beam is 500 mm, upper plate is16mm,down plate is 18mm, middle plate is 10 mm.
    Platform plate5mm Diamond plate
    Tire Type and quantity11.00R20 12units radial tire
    LadderWith Ladder
    Traction Pin90MM or 50MM
    Spare Wheel Bracket2 pieces
    Tool Box2 Standard
    Landing GearStandard 28T
    Brake systemDual Line braking system,
    Brake air chamberTwo double and two single chamber
    Electrical system1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness)
    Tail lamp with turn signal, brake light & reflector, side lamp etc.
    One set 6-core standard Cable.
    Side GuardAccording to customer’s requirement
    PaintingColor as customer’s requirement
    PackingNUDE, Polish with wax before shipping
    Delivery wayTransfer to Tianjin Port, and carry bulk shipment.

    3 Line 6 Axles Truck Trailer Low Bed , Low Bed Lorry Loading 100 Tons


    -2. Our Low Bed Trailer Advantage.


    -. The material use high strength steel, the chassis more durable and stronger.

    -. The loading area height is only 1m reduce the transport height.

    -. With good brand axles, ladder, tire, brake system, support leg spare parts.

    -. Also supply tech support and one year quality warranty.
